    Pre - Engineered Building Workshop Steel Structure Light Steel Prefab Metal Workshop

    Pre-Engineered Building With Light Steel Structure

    Product Description:
    QHHK offers virtually any type of structural design required. Your building square footage, local codes and wind, rain, and seismic requirements will determine the type of structural system that will apply. Other considerations include interior space requirements where clear spans may or may not be required. Standard bay lengths are 6m,7.5m, and 9m between mainframes. A variety of end wall designs are available depending upon specific building demands. Post and beam end walls are standard optional"rigid frame" end wall designs are also available when there may be a need to add to the building in the future or perhaps a need for a total opening such as an aircraft hangar door. Our staff of experienced professionals can be of great assistance in determining the right structure for your application.
    Steel Structure Application Fields:

    We cater for every market from warehouses, workshops to 4S car exhibition centers, shopping mall, aircraft hangers, poultry & pig sheds, container houses, agricultural& commercial buildings and so on.


    Characteristics:


    1. Cost savings: be inexpensive to manufacture, requires less maintenance than other traditional building methods. Moreover, 98% of all steel structure can be recycled into new steel products without reducing physical properties.


    2. Quick erection: steel structures can be erected quickly. The accuracy of steel components speeds up the process and allows monitoring of the management software to complete sooner.


    3. Health and safety: Structural Steel is manufactured at the factory and rapid erection on the construction site by skilled personnel making steel structure safe. Industry surveys consistently demonstrate that steel structure is the safest solution. There is very little noise and dust in the process of steel structure erection because structural steel members are fabricated at the factory.


    4. Flexibility: Can be modified in the future for the new application, loading conditions, vertical expansions and changes in owner’s desires in ways that other framing systems cannot accomplish.


    Main parts of the steel structures and technical parameters:


    Main Steel Frame System
    Main structureH section steel Q345, alkyd painting, two primary painting, two finish painting.
    Roof purlinXZ160*60*20*2.5, galvanized
    Wall purlinXZ160*60*20*2.5, galvanized
    Intensive boltGrade 10.9
    Turn buckle boltM20+2, steel Q235, processing
    Anchor boltM24, steel Q235, processing
    Ordinary boltGalvanized bolt M20
    Ordinary boltGalvanized bolt M12
    Brace nutGalvanized bolt M12
    Bracing System
    Cross braceΦ20 round steel bar Q235, process and painted (alkyd painting)
    Angle braceL50*5 angle steel Q235, process and painted (alkyd painting)
    Column bracingΦ25 round steel bar Q235, process and painted (alkyd painting)
    Tie barΦ127*3 steel pipe Q235, process and painted (alkyd painting)
    Batter braceΦ32*2.5, Φ12 round steel bar Q235, process and painted (alkyd painting)
    Wall & Roof System
    Roof panelCorrugated steel plate or sandwich panel (EPS/fiber glass/rock wool/PU)
    Wall panelCorrugated steel plate or sandwich panel (EPS/fiber glass/rock wool/PU)
    Edge cover0.4mm color plate, angle Alu.
    Fittings & accessoriesNails, glue etc.
    Unpowered ventilatorDiameter Φ600, stainless steel
    Sky lighting band1.2mm FRP, double layer
    Sliding doorsandwich panel door
    Roof drainage system
    Gutter0.8mm color steel plate
    Rainspout pipesΦ160 PVC pipe

    Product category:

    Pre - Engineered Building Workshop Steel Structure Light Steel Prefab Metal Workshop

    Detail Images:

    We can produce various steel structure components like H beam, box column, grid column, round column etc.

    Pre - Engineered Building Workshop Steel Structure Light Steel Prefab Metal Workshop
